System Disable Modern Standby in Windows 10 and Windows 11



This tutorial will show you how to disable Modern Standby (S0 Low Power Idle) to enable S3 support on a Windows 10 and Windows 11 device.

In Windows 10 and Windows 11, there are two power models for PCs: S3 and Modern Standby (S0 Low Power Idle). The S3 power model is an older standard and is not capable of the instant on that consumers expect from modern devices. Modern Standby is capable of leveraging all the capabilities of a modern chipset and can be integrated across the breadth of tablets and PCs today. The first iteration of Modern Standby was Connected Standby, which first shipped in Windows 8 and Windows 8.1. Modern Standby expands upon the Windows 8.x Connected Standby concept, allowing for flexibility in component selection and the ability for the OS to manage network connectivity in standby.

Windows 10 and Windows 11 Modern Standby (Modern Standby) expands the Windows 8.1 Connected Standby power model. Connected Standby, and consequently Modern Standby, enable an instant on / instant off user experience, similar to smartphone power models. Just like the phone, the S0 low power idle model enables the system to stay connected to the network while in a low power mode.

Although Modern Standby enables an instant on/off user experience like Connected Standby, Modern Standby is more inclusive than the Windows 8.1 Connected Standby power model. Modern Standby allows for market segments previously limited to the Traditional Sleep (S3) power model to take advantage of the low power idle model. Example systems include systems based on rotational media and hybrid media (for example, SSD + HDD or SSHD) and/or a NIC that doesn’t support all of the prior requirements for Connected Standby.

Modern Standby systems can be connected (enabled), disconnected (disabled), or managed by Windows to allow network connectivity during standby. This behavior is dictated by the hardware and/or by configuration.
  • Connected Modern Standby will allow you to stay connected to the network while in standby to still receive and get notifications about email, VoIP calls, and such, but it will use more battery.
  • Disconnected Modern Standby will allow longer battery life, but you will no longer have the advantages of staying connected to the network while in standby.
  • Managed by Windows will allow Windows to manage network connectivity during standby.
On any Modern Standby system (whether connected or disconnected), the system remains in S0 while in standby, allowing the following scenarios to work:
  • Background activity
  • Faster resume from a low power state
On systems that are connected while in standby, wakes based on specific network patterns may also be set by the operating system to enable apps to receive the latest content such as incoming email, VoIP calls, or news articles.

See also:

If you disabled Modern Standby and your PC crashes when entering S3, you can press and hold the power button to force a hard shut down, press the power button again to turn on, and enable Modern Standby below again.

This can happen if the device OEM has not included support for S3 in the BIOS/UEFI firmware.


You must be signed in as an administrator to enable or disable Modern Standby.

You cannot enable Modern Standby on a device that didn't originally support it.



Contents

  • Option One: Enable or Disable Modern Standby using Command
  • Option Two: Enable or Disable Modern Standby using REG file


EXAMPLE: Modern Standby enabled and disabled







Option One

Enable or Disable Modern Standby using Command


1 Open an elevated command prompt in Windows 10, or open Windows Terminal (Admin) in Windows 11, and select either Windows PowerShell or Command Prompt.

2 Copy and paste the command below you want to use into the console, and press Enter. (see screenshots below)

(Enable Modern Standby - default)​
reg delete "HKLM\System\CurrentControlSet\Control\Power" /v PlatformAoAcOverride /f​


OR​

(Disable Modern Standby)​
reg add HKLM\System\CurrentControlSet\Control\Power /v PlatformAoAcOverride /t REG_DWORD /d 0 /f​


3 Restart the computer to apply.




Option Two

Enable or Disable Modern Standby using REG file


1 Do step 2 (enable) or step 3 (disable) below for what you want.

2 Enable Modern Standby

This is the default setting.


A) Click/tap on the Download button below to download the REG file below, and go to step 4 below.​

Enable_Modern_Standby.reg​


(Contents of REG file for reference)
Code:
Windows Registry Editor Version 5.00

[HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\Power]
"PlatformAoAcOverride"=-

3 Disable Modern Standby

A) Click/tap on the Download button below to download the REG file below, and go to step 4 below.​

Disable_Modern_Standby.reg​


(Contents of REG file for reference)
Code:
Windows Registry Editor Version 5.00

[HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\Power]
"PlatformAoAcOverride"=dword:00000000

4 Save the .reg file to your desktop.

5 Double click/tap on the downloaded .reg file to merge it.

6 When prompted, click/tap on Run, Yes (UAC), Yes, and OK to approve the merge.

7 Restart the computer to apply.

8 You can now delete the downloaded .reg file if you like.


That's it,
Shawn Brink


Related Tutorials



Attachments

Last edited:
Click to expand...
Caledon Ken,

Have you tried using Macrium scheduler whilst stopping S0 Modern standby progressing into its later phases?
I successfully use [Windows] task scheduler to run tasks whilst the computer is in S0 Modern standby. I described my experiences in Running scripts during S0 Modern standby - my post #86 - ElevenForum
I know nothing about Macrium scheduler.



Merry Christmas,
Denis


My Computer

System One

  • OS
    Windows 11 Home x64 Version 23H2 Build 22631.3447
No Denis I just used what I think you previously recommended, I set Windows "Sleep" option to never.

I think the real point is, as an industry, fix / modify modern sleep and the apps that will want to run a task. I know of two that don't operate as they should, my opinion, Macrium and Super Antivirus. I'm sure there are others.

Really I don't care if it the hardware manufactures, Microsoft or the App developers. They should agree to a standard and it should work, as it did under S3.

The only reason I rejoined the thread was I saw people saying Modern Sleep was working fine so I thought / prayed the industry had fixed it.

Thanks for the response. I will review again.


My Computer

System One

  • OS
    Windows 11 Pro x64 Version V23H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom
    CPU
    i7-8700K
    Motherboard
    Asus Maximus X Code - Z370
    Memory
    G.Skill Trident Z 3200MHz F4-3200C16D-16GTZ (2) 32GB
    Graphics Card(s)
    Intel UHD Graphics 630
    Sound Card
    Integrated ROG SupremeFX
    Monitor(s) Displays
    Asus VP279 27", Samsung BX2431 24"
    Screen Resolution
    1920 x 1080
    Hard Drives
    Samsung M.2 NVMe 960 EVO 500GB Boot,
    Samsung 840 EVO 250GB (System Copy Drive),
    Samsung 860 EVO 1TB (Primary Data Drive),
    WD Black 500GB (Data Copy Drive)
    ICY Dock 5.25 2.5/3.5 Bays MB971SP-B
    PSU
    Corsair RM 650i +Gold
    Case
    Phanteks Enthroo Primo
    Cooling
    Corsair Hydro H150i, 360mm Rad & Five Corsair 140mm Pro ML Case Fans
    Keyboard
    das Keyboard MX Brown Mechanical Switches Model DASKMKPROSIL-3G7-r1.0
    Mouse
    Logitech MX Master 3 Wireless & Bluetooth
    Internet Speed
    500Mb +
    Browser
    Chrome (Pri), Firefox (Sec)
    Antivirus
    Malwarebytes Premium, SuperAntiSpyware Pro (Licensed)
    Other Info
    Microsoft LifeCam HD,
    APC Back-UPS Pro 1500,
    Macrium (Licensed),
    Microsoft 365,
    Wise Disk Cleaner,
    Crystal Disk Info,
    Screenpresso (Licensed),
    AnyDesk (Licensed),
Ken,

I agree that the definition of S0 Modern standby ought to be amended to allow use of Task scheduler jobs.
I think the whole thing is an Intel initiative but MS & the computer makers have certainly taken it up with a vengeance.

If you are going to experiment with running scripts then I'll post my latest version of the script that rouses the display from S0 Modern standby & initiates the real script of interest. The rousing script is run from Task scheduler.


Denis


My Computer

System One

  • OS
    Windows 11 Home x64 Version 23H2 Build 22631.3447
No I won't be experimenting, I'll have another read. Things work as is, no sleep, and life is far to short.


My Computer

System One

  • OS
    Windows 11 Pro x64 Version V23H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom
    CPU
    i7-8700K
    Motherboard
    Asus Maximus X Code - Z370
    Memory
    G.Skill Trident Z 3200MHz F4-3200C16D-16GTZ (2) 32GB
    Graphics Card(s)
    Intel UHD Graphics 630
    Sound Card
    Integrated ROG SupremeFX
    Monitor(s) Displays
    Asus VP279 27", Samsung BX2431 24"
    Screen Resolution
    1920 x 1080
    Hard Drives
    Samsung M.2 NVMe 960 EVO 500GB Boot,
    Samsung 840 EVO 250GB (System Copy Drive),
    Samsung 860 EVO 1TB (Primary Data Drive),
    WD Black 500GB (Data Copy Drive)
    ICY Dock 5.25 2.5/3.5 Bays MB971SP-B
    PSU
    Corsair RM 650i +Gold
    Case
    Phanteks Enthroo Primo
    Cooling
    Corsair Hydro H150i, 360mm Rad & Five Corsair 140mm Pro ML Case Fans
    Keyboard
    das Keyboard MX Brown Mechanical Switches Model DASKMKPROSIL-3G7-r1.0
    Mouse
    Logitech MX Master 3 Wireless & Bluetooth
    Internet Speed
    500Mb +
    Browser
    Chrome (Pri), Firefox (Sec)
    Antivirus
    Malwarebytes Premium, SuperAntiSpyware Pro (Licensed)
    Other Info
    Microsoft LifeCam HD,
    APC Back-UPS Pro 1500,
    Macrium (Licensed),
    Microsoft 365,
    Wise Disk Cleaner,
    Crystal Disk Info,
    Screenpresso (Licensed),
    AnyDesk (Licensed),
Caledon Ken said:
No I won't be experimenting, I'll have another read. Things work as is, no sleep, and life is far to short.
Click to expand...
Now I am even more confused than my avatar TBH. If things work as is, and life is far too short, then why spend time complaining about things that work as is, and why spend time having another read? I was going to experiment soon. But life is far too short so I think I will just go back to sleep then. lol


My Computers

System One System Two

  • OS
    11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Asus TUF Gaming F16 (2024)
    CPU
    i7 13650HX
    Memory
    16GB DDR5
    Graphics Card(s)
    GeForce RTX 4060 Mobile
    Sound Card
    Eastern Electric MiniMax DAC Supreme; Emotiva UMC-200; Astell & Kern AK240
    Monitor(s) Displays
    Sony Bravia XR-55X90J
    Screen Resolution
    3840×2160
    Hard Drives
    512GB SSD internal
    37TB external
    PSU
    Li-ion
    Cooling
    2× Arc Flow Fans, 4× exhaust vents, 5× heatpipes
    Keyboard
    Logitech K800
    Mouse
    Logitech G402
    Internet Speed
    20Mbit/s up, 250Mbit/s down
    Browser
    FF
  • Operating System
    11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Medion S15450
    CPU
    i5 1135G7
    Memory
    16GB DDR4
    Graphics card(s)
    Intel Iris Xe
    Sound Card
    Eastern Electric MiniMax DAC Supreme; Emotiva UMC-200; Astell & Kern AK240
    Monitor(s) Displays
    Sony Bravia XR-55X90J
    Screen Resolution
    3840×2160
    Hard Drives
    2TB SSD internal
    37TB external
    PSU
    Li-ion
    Mouse
    Logitech G402
    Keyboard
    Logitech K800
    Internet Speed
    20Mbit/s up, 250Mbit/s down
    Browser
    FF
Reading through this thread since I have such a weird issue with my Lenovo thinkpad (T14G3 AMD). It happened since I first got it after a windows update, but through various uninstalls of drivers and reinstalls of lenovo drivers i got it working again. I fixed it, but then windows updated to 24H2 (i have driver updates disabled).

What ends up happening is the laptop will go to sleep (the lenovo red dot will blink slowly), and sometimes when i open the lid, 1 of 2 things happen:

1) The laptop doesnt wake, i press the power button, the led blinks and keyboard lights up, but no screen
2) Laptop wakes, but then windows gets frozen on the 'welcome' screen after i use my login credentials

Ideally whats supposed to happen is this:
- I close the lid, laptop sleeps (slow blink), and if x-% drains (standby percent), then the laptop goes into a deepsleep (no more blinking led)
- When the lid is opened again (with no buttons pressed), the laptop should resume having only drained that x-% (maybe a little more based on how long in that deepsleep)

What i've tried:
- Device manager: reinstalling Lenovo PM Device, power and battery, AMD IO. I've tried all with several versions of each but still experiencing issues from wake.
- Power plan, i reverted my balanced plan to default and copied it to a new plan, i used PowerSettingsExplorer.exe and unhid a few settings. set standby % to 3% (my preference) and tweaked a few other settings
- Laptop doesnt and has never supported S3, only S0.


Any other ideas/suggestions? Becoming such a nuisance, was working flawlessly before the windows update. As a last resort ill undo the update, but i did that last time this happened, and had to do the driver dance again


My Computer

System One

  • OS
    Win11-24H2
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo T14G3
    CPU
    AMD6850u
    Memory
    32gb
RandomPJ said:
Reading through this thread since I have such a weird issue with my Lenovo thinkpad (T14G3 AMD). It happened since I first got it after a windows update, but through various uninstalls of drivers and reinstalls of lenovo drivers i got it working again. I fixed it, but then windows updated to 24H2 (i have driver updates disabled).

What ends up happening is the laptop will go to sleep (the lenovo red dot will blink slowly), and sometimes when i open the lid, 1 of 2 things happen:

1) The laptop doesnt wake, i press the power button, the led blinks and keyboard lights up, but no screen
2) Laptop wakes, but then windows gets frozen on the 'welcome' screen after i use my login credentials

Ideally whats supposed to happen is this:
- I close the lid, laptop sleeps (slow blink), and if x-% drains (standby percent), then the laptop goes into a deepsleep (no more blinking led)
- When the lid is opened again (with no buttons pressed), the laptop should resume having only drained that x-% (maybe a little more based on how long in that deepsleep)

What i've tried:
- Device manager: reinstalling Lenovo PM Device, power and battery, AMD IO. I've tried all with several versions of each but still experiencing issues from wake.
- Power plan, i reverted my balanced plan to default and copied it to a new plan, i used PowerSettingsExplorer.exe and unhid a few settings. set standby % to 3% (my preference) and tweaked a few other settings
- Laptop doesnt and has never supported S3, only S0.


Any other ideas/suggestions? Becoming such a nuisance, was working flawlessly before the windows update. As a last resort ill undo the update, but i did that last time this happened, and had to do the driver dance again
Click to expand...

Hello, and welcome. :alien:

As a test, turn off Fast Startup like below and restart the computer to see if it still does this. Fast Startup used to be the cause of similar startup issues like this. I hadn't seen any issues with it in W11, but worth a try.

www.elevenforum.com

Turn On or Off Fast Startup in Windows 11

This tutorial will show you how to turn on or off fast startup in Windows 11. There are three startup modes in Windows: Cold (traditional) Wake-from-hibernation Fast Starting with Windows 8.x, the default shutdown and restart scenario has been updated and named fast startup. Fast startup...
www.elevenforum.com www.elevenforum.com


My Computers

System One System Two

  • OS
    Windows 11 Pro for Workstations
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom self build
    CPU
    Intel i7-8700K 5 GHz
    Motherboard
    ASUS ROG Maximus XI Formula Z390
    Memory
    64 GB (4x16GB) G.SKILL TridentZ RGB DDR4 3600 MHz (F4-3600C18D-32GTZR)
    Graphics Card(s)
    ASUS ROG-STRIX-GTX1080TI-O11G-GAMING (11GB GDDR5X)
    Sound Card
    Integrated Digital Audio (S/PDIF)
    Monitor(s) Displays
    2 x Samsung Odyssey G75 27"
    Screen Resolution
    2560x1440
    Hard Drives
    1TB Samsung 990 PRO M.2,
    4TB Samsung 990 PRO M.2,
    8TB WD MyCloudEX2Ultra NAS
    PSU
    Seasonic Prime Titanium 850W
    Case
    Thermaltake Core P3 wall mounted
    Cooling
    Corsair Hydro H115i
    Keyboard
    Logitech wireless K800
    Mouse
    Logitech MX Master 3
    Internet Speed
    1 Gbps Download and 35 Mbps Upload
    Browser
    Google Chrome
    Antivirus
    Microsoft Defender and Malwarebytes Premium
    Other Info
    Logitech Z625 speaker system,
    Logitech BRIO 4K Pro webcam,
    HP Color LaserJet Pro MFP M477fdn,
    CyberPower CP1500PFCLCD
    Galaxy S23 Plus phone
  • Operating System
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Surface Laptop 7 Copilot+ PC
    CPU
    Snapdragon X Elite (12 core) 3.42 GHz
    Memory
    16 GB LPDDR5x-7467 MHz
    Monitor(s) Displays
    15" HDR
    Screen Resolution
    2496 x 1664
    Hard Drives
    1 TB SSD
    Internet Speed
    Wi-Fi 7 and Bluetooth 5.4
    Browser
    Chrome and Edge
    Antivirus
    Windows Defender
Things don't work as they should. A task should be able to kick off in modern standby and I shouldn't have to create scripts to make things work. Setting device not to sleep is a work around as is creating scripts.


My Computer

System One

  • OS
    Windows 11 Pro x64 Version V23H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom
    CPU
    i7-8700K
    Motherboard
    Asus Maximus X Code - Z370
    Memory
    G.Skill Trident Z 3200MHz F4-3200C16D-16GTZ (2) 32GB
    Graphics Card(s)
    Intel UHD Graphics 630
    Sound Card
    Integrated ROG SupremeFX
    Monitor(s) Displays
    Asus VP279 27", Samsung BX2431 24"
    Screen Resolution
    1920 x 1080
    Hard Drives
    Samsung M.2 NVMe 960 EVO 500GB Boot,
    Samsung 840 EVO 250GB (System Copy Drive),
    Samsung 860 EVO 1TB (Primary Data Drive),
    WD Black 500GB (Data Copy Drive)
    ICY Dock 5.25 2.5/3.5 Bays MB971SP-B
    PSU
    Corsair RM 650i +Gold
    Case
    Phanteks Enthroo Primo
    Cooling
    Corsair Hydro H150i, 360mm Rad & Five Corsair 140mm Pro ML Case Fans
    Keyboard
    das Keyboard MX Brown Mechanical Switches Model DASKMKPROSIL-3G7-r1.0
    Mouse
    Logitech MX Master 3 Wireless & Bluetooth
    Internet Speed
    500Mb +
    Browser
    Chrome (Pri), Firefox (Sec)
    Antivirus
    Malwarebytes Premium, SuperAntiSpyware Pro (Licensed)
    Other Info
    Microsoft LifeCam HD,
    APC Back-UPS Pro 1500,
    Macrium (Licensed),
    Microsoft 365,
    Wise Disk Cleaner,
    Crystal Disk Info,
    Screenpresso (Licensed),
    AnyDesk (Licensed),
Brink said:
Hello, and welcome. :alien:

As a test, turn off Fast Startup like below and restart the computer to see if it still does this. Fast Startup used to be the cause of similar startup issues like this. I hadn't seen any issues with it in W11, but worth a try.

www.elevenforum.com

Turn On or Off Fast Startup in Windows 11

This tutorial will show you how to turn on or off fast startup in Windows 11. There are three startup modes in Windows: Cold (traditional) Wake-from-hibernation Fast Starting with Windows 8.x, the default shutdown and restart scenario has been updated and named fast startup. Fast startup...
www.elevenforum.com www.elevenforum.com
Click to expand...


Fast startups disabled :( thats something i already checked. Wasnt sure if this sleep/standby issue is driver related or windows software. Its such a weird issue. Ive tried lenovo forums and theyre not too helpful with more things to try.


My Computer

System One

  • OS
    Win11-24H2
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo T14G3
    CPU
    AMD6850u
    Memory
    32gb
Update: with updating all my drivers to the latest, and installing GPU/CPU AMD drivers from AMD (Adrenaline). Knock on wood its been good.. I've also used powersettingsexplorer to unhide a ton of options to tweak which has been nice. I enabled hibernate from the cmd (powercfg /h on), but then disabled it in the system settings which for some reason seems to have solved my issues as well. So not sure what weird combination resolved the issue, but im not complaining (as long as it works)


My Computer

System One

  • OS
    Win11-24H2
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo T14G3
    CPU
    AMD6850u
    Memory
    32gb
You must log in or register to reply here.

Similar Windows 11 Tutorials

  • Article Article
Apps Enable or Disable Model Training in Copilot on Web, Windows 11, and Windows 10
Replies
0
Views
2K
Brink
Brink
  • Article Article
Browsers and Mail Enable or Disable Collections in Microsoft Edge in Windows 11
Replies
0
Views
909
Brink
Brink
  • Article Article
System Enable or Disable Show Battery Percentage on Taskbar in Windows 11
Replies
6
Views
2K
garlin
G
  • Article Article
Apps Install PowerToys Group Policies in Windows 10 and 11
Replies
1
Views
1K
pseymour
pseymour
  • Article Article
Apps Enable or Disable Cocreator in Paint app in Windows 11
Replies
0
Views
1K
Brink
Brink
  • Article Article
Apps Enable or Disable Image Creator in Paint app in Windows 11
Replies
0
Views
1K
Brink
Brink
  • Article Article
Network and Internet Enable or Disable Thumbnail Previews on Network Files and Folders in File Explorer in Windows 11
Replies
0
Views
2K
Brink
Brink

Latest Support Threads

Latest Tutorials

Back
Top Bottom
