Ist there a list of wallpaper customization applications who are preventing the update to Windows 11 24H2?

On the official Microsoft site there is a description that some wallpaper customization apps are preventing the update, but I don't have any wallpapers apps installed:
learn.microsoft.com

Windows 11, version 24H2 known issues and notifications

View announcements and review known issues and fixes for Windows 11, version 24H2
learn.microsoft.com

But the registry shows that the Safeguard 52754008 is preventing my update.

Windows Build/Version
Windows 11 23H2 (Build 22631.5189)

My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Asus Zenbook Duo
    Memory
    16 GB
Hi, Chris, welcome.

There are no native apps like that to Windows 11 that I have ever been aware of.

Could you please supply the exact model number of your ASUS which is probably located underneath the laptop.


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2 Build 22631.5039
    Computer type
    PC/Desktop
    Manufacturer/Model
    Sin-built
    CPU
    Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (4th Gen?)
    Motherboard
    ASUS ROG Maximus VI Formula
    Memory
    32.0 GB of I forget and the box is in storage.
    Graphics Card(s)
    Gigabyte nVidia GeForce GTX 1660 Super OC 6GB
    Sound Card
    Onboard
    Monitor(s) Displays
    5 x LG 25MS500-B - 1 x 24MK430H-B - 1 x Wacom Pro 22" Tablet
    Screen Resolution
    All over the place
    Hard Drives
    Too many to list.
    OS on Samsung 1TB 870 QVO SATA
    PSU
    Silverstone 1500
    Case
    NZXT Phantom 820 Full-Tower Case
    Cooling
    Noctua NH-D15 Elite Class Dual Tower CPU Cooler / 6 x EziDIY 120mm / 2 x Corsair 140mm somethings / 1 x 140mm Thermaltake something / 2 x 200mm Corsair.
    Keyboard
    Corsair K95 / Logitech diNovo Edge Wireless
    Mouse
    Logitech: G402 / G502 / Mx Masters / MX Air Cordless
    Internet Speed
    1000/400Mbps
    Browser
    All sorts
    Antivirus
    Kaspersky Premium
    Other Info
    I’m on a horse.
  • Operating System
    Windows 11 Pro 23H2 Build: 22631.4249
    Computer type
    Laptop
    Manufacturer/Model
    LENOVO Yoga 7i EVO OLED 14" Touchscreen i5 12 Core 16GB/512GB
    CPU
    Intel Core 12th Gen i5-1240P Processor (1.7 - 4.4GHz)
    Memory
    16GB LPDDR5 RAM
    Graphics card(s)
    Intel Iris Xe Graphics Processor
    Sound Card
    Optimized with Dolby Atmos®
    Screen Resolution
    QHD 2880 x 1800 OLED
    Hard Drives
    M.2 512GB
    Antivirus
    Defender / Malwarebytes
    Other Info
    …still on a horse.
As far as I understand; The safeguard is generally something to do with Hardware in your system that Microsoft is preventing an update from, due to known issues between the update and your Laptop/PC.

Perhaps run a check to see that your Drivers and BIOS are up to date.


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2 Build 22631.5039
    Computer type
    PC/Desktop
    Manufacturer/Model
    Sin-built
    CPU
    Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (4th Gen?)
    Motherboard
    ASUS ROG Maximus VI Formula
    Memory
    32.0 GB of I forget and the box is in storage.
    Graphics Card(s)
    Gigabyte nVidia GeForce GTX 1660 Super OC 6GB
    Sound Card
    Onboard
    Monitor(s) Displays
    5 x LG 25MS500-B - 1 x 24MK430H-B - 1 x Wacom Pro 22" Tablet
    Screen Resolution
    All over the place
    Hard Drives
    Too many to list.
    OS on Samsung 1TB 870 QVO SATA
    PSU
    Silverstone 1500
    Case
    NZXT Phantom 820 Full-Tower Case
    Cooling
    Noctua NH-D15 Elite Class Dual Tower CPU Cooler / 6 x EziDIY 120mm / 2 x Corsair 140mm somethings / 1 x 140mm Thermaltake something / 2 x 200mm Corsair.
    Keyboard
    Corsair K95 / Logitech diNovo Edge Wireless
    Mouse
    Logitech: G402 / G502 / Mx Masters / MX Air Cordless
    Internet Speed
    1000/400Mbps
    Browser
    All sorts
    Antivirus
    Kaspersky Premium
    Other Info
    I’m on a horse.
  • Operating System
    Windows 11 Pro 23H2 Build: 22631.4249
    Computer type
    Laptop
    Manufacturer/Model
    LENOVO Yoga 7i EVO OLED 14" Touchscreen i5 12 Core 16GB/512GB
    CPU
    Intel Core 12th Gen i5-1240P Processor (1.7 - 4.4GHz)
    Memory
    16GB LPDDR5 RAM
    Graphics card(s)
    Intel Iris Xe Graphics Processor
    Sound Card
    Optimized with Dolby Atmos®
    Screen Resolution
    QHD 2880 x 1800 OLED
    Hard Drives
    M.2 512GB
    Antivirus
    Defender / Malwarebytes
    Other Info
    …still on a horse.
antspants said:
As far as I understand; The safeguard is generally something to do with Hardware in your system that Microsoft is preventing an update from, due to known issues between the update and your Laptop/PC.

Perhaps run a check to see that your Drivers and BIOS are up to date.
Click to expand...
Seems not with the 24H2 update, because the link I have posted lists apps and hardware related things.


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Asus Zenbook Duo
    Memory
    16 GB
A brief page:

learn.microsoft.com

Safeguard holds for Windows

What are safeguard holds? How to can you tell if a safeguard hold is in effect, and what to do about it.
learn.microsoft.com

Safeguard holds could be attributed to many things, for example, there was new one put on systems only recently:

www.bleepingcomputer.com

Windows 11 24H2 blocked on PCs with code-obfuscation driver BSODs

Microsoft has introduced a new Windows 11 24H2 safeguard hold for systems running security or enterprise software using SenseShield Technology's sprotect.sys driver.
www.bleepingcomputer.com www.bleepingcomputer.com

The trick is to find out why your ASUS has one, I am not sure it would be due to an app, but I suppose could possibly be due to a driver that is installed by an app
As for Wallpaper Software. You said you don’t have any. Unless one was installed while you were installing something else, there isn’t a native one to Windows.

Check for Driver and BIOS updates would be my first try.

Someone with more knowledge of Safeguard Holds should hopefully chime in.


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2 Build 22631.5039
    Computer type
    PC/Desktop
    Manufacturer/Model
    Sin-built
    CPU
    Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (4th Gen?)
    Motherboard
    ASUS ROG Maximus VI Formula
    Memory
    32.0 GB of I forget and the box is in storage.
    Graphics Card(s)
    Gigabyte nVidia GeForce GTX 1660 Super OC 6GB
    Sound Card
    Onboard
    Monitor(s) Displays
    5 x LG 25MS500-B - 1 x 24MK430H-B - 1 x Wacom Pro 22" Tablet
    Screen Resolution
    All over the place
    Hard Drives
    Too many to list.
    OS on Samsung 1TB 870 QVO SATA
    PSU
    Silverstone 1500
    Case
    NZXT Phantom 820 Full-Tower Case
    Cooling
    Noctua NH-D15 Elite Class Dual Tower CPU Cooler / 6 x EziDIY 120mm / 2 x Corsair 140mm somethings / 1 x 140mm Thermaltake something / 2 x 200mm Corsair.
    Keyboard
    Corsair K95 / Logitech diNovo Edge Wireless
    Mouse
    Logitech: G402 / G502 / Mx Masters / MX Air Cordless
    Internet Speed
    1000/400Mbps
    Browser
    All sorts
    Antivirus
    Kaspersky Premium
    Other Info
    I’m on a horse.
  • Operating System
    Windows 11 Pro 23H2 Build: 22631.4249
    Computer type
    Laptop
    Manufacturer/Model
    LENOVO Yoga 7i EVO OLED 14" Touchscreen i5 12 Core 16GB/512GB
    CPU
    Intel Core 12th Gen i5-1240P Processor (1.7 - 4.4GHz)
    Memory
    16GB LPDDR5 RAM
    Graphics card(s)
    Intel Iris Xe Graphics Processor
    Sound Card
    Optimized with Dolby Atmos®
    Screen Resolution
    QHD 2880 x 1800 OLED
    Hard Drives
    M.2 512GB
    Antivirus
    Defender / Malwarebytes
    Other Info
    …still on a horse.
You could possibly do an in-place upgrade to jump to 24H2

Disable the internet or tell it to not check for updates, I’d disable the internet. (If you’re doing it via 24H2 media created on a USB)

Option one needs the internet
Option two doesn’t (Uncheck check for updates)

www.elevenforum.com

Repair Install Windows 11 with an In-place Upgrade

This tutorial will show you how to do a repair install of Windows 11 by performing an in-place upgrade without losing anything. If you need to repair or create a new recovery partition or having problems with the Windows 11 operating system on your PC, and the usual solutions will not fix it...
www.elevenforum.com www.elevenforum.com


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2 Build 22631.5039
    Computer type
    PC/Desktop
    Manufacturer/Model
    Sin-built
    CPU
    Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (4th Gen?)
    Motherboard
    ASUS ROG Maximus VI Formula
    Memory
    32.0 GB of I forget and the box is in storage.
    Graphics Card(s)
    Gigabyte nVidia GeForce GTX 1660 Super OC 6GB
    Sound Card
    Onboard
    Monitor(s) Displays
    5 x LG 25MS500-B - 1 x 24MK430H-B - 1 x Wacom Pro 22" Tablet
    Screen Resolution
    All over the place
    Hard Drives
    Too many to list.
    OS on Samsung 1TB 870 QVO SATA
    PSU
    Silverstone 1500
    Case
    NZXT Phantom 820 Full-Tower Case
    Cooling
    Noctua NH-D15 Elite Class Dual Tower CPU Cooler / 6 x EziDIY 120mm / 2 x Corsair 140mm somethings / 1 x 140mm Thermaltake something / 2 x 200mm Corsair.
    Keyboard
    Corsair K95 / Logitech diNovo Edge Wireless
    Mouse
    Logitech: G402 / G502 / Mx Masters / MX Air Cordless
    Internet Speed
    1000/400Mbps
    Browser
    All sorts
    Antivirus
    Kaspersky Premium
    Other Info
    I’m on a horse.
  • Operating System
    Windows 11 Pro 23H2 Build: 22631.4249
    Computer type
    Laptop
    Manufacturer/Model
    LENOVO Yoga 7i EVO OLED 14" Touchscreen i5 12 Core 16GB/512GB
    CPU
    Intel Core 12th Gen i5-1240P Processor (1.7 - 4.4GHz)
    Memory
    16GB LPDDR5 RAM
    Graphics card(s)
    Intel Iris Xe Graphics Processor
    Sound Card
    Optimized with Dolby Atmos®
    Screen Resolution
    QHD 2880 x 1800 OLED
    Hard Drives
    M.2 512GB
    Antivirus
    Defender / Malwarebytes
    Other Info
    …still on a horse.
Last option from me:

www.elevenforum.com

Enable or Disable Safeguard Holds for Feature Updates in Windows 11

This tutorial will show you how to enable or disable safeguard holds for feature updates in Windows 10 and Windows 11. Feature updates are new versions of Windows that are released via Windows Update twice a year usually around spring and fall. Microsoft uses quality and compatibility data to...
www.elevenforum.com www.elevenforum.com


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2 Build 22631.5039
    Computer type
    PC/Desktop
    Manufacturer/Model
    Sin-built
    CPU
    Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (4th Gen?)
    Motherboard
    ASUS ROG Maximus VI Formula
    Memory
    32.0 GB of I forget and the box is in storage.
    Graphics Card(s)
    Gigabyte nVidia GeForce GTX 1660 Super OC 6GB
    Sound Card
    Onboard
    Monitor(s) Displays
    5 x LG 25MS500-B - 1 x 24MK430H-B - 1 x Wacom Pro 22" Tablet
    Screen Resolution
    All over the place
    Hard Drives
    Too many to list.
    OS on Samsung 1TB 870 QVO SATA
    PSU
    Silverstone 1500
    Case
    NZXT Phantom 820 Full-Tower Case
    Cooling
    Noctua NH-D15 Elite Class Dual Tower CPU Cooler / 6 x EziDIY 120mm / 2 x Corsair 140mm somethings / 1 x 140mm Thermaltake something / 2 x 200mm Corsair.
    Keyboard
    Corsair K95 / Logitech diNovo Edge Wireless
    Mouse
    Logitech: G402 / G502 / Mx Masters / MX Air Cordless
    Internet Speed
    1000/400Mbps
    Browser
    All sorts
    Antivirus
    Kaspersky Premium
    Other Info
    I’m on a horse.
  • Operating System
    Windows 11 Pro 23H2 Build: 22631.4249
    Computer type
    Laptop
    Manufacturer/Model
    LENOVO Yoga 7i EVO OLED 14" Touchscreen i5 12 Core 16GB/512GB
    CPU
    Intel Core 12th Gen i5-1240P Processor (1.7 - 4.4GHz)
    Memory
    16GB LPDDR5 RAM
    Graphics card(s)
    Intel Iris Xe Graphics Processor
    Sound Card
    Optimized with Dolby Atmos®
    Screen Resolution
    QHD 2880 x 1800 OLED
    Hard Drives
    M.2 512GB
    Antivirus
    Defender / Malwarebytes
    Other Info
    …still on a horse.
I parsed a list of blocked wallpaper apps for Safeguard 52754008:

360DesktopLite.exe
360DesktopLite64.exe
360huabao.exe
animation_desktop_webgl.exe
Aura
coodesker.exe
coodesker-x64.exe
DesktopDynamicLyric.exe
DesktopMgr.exe
DesktopMgr64.exe
DesktopPlus.exe
DesktopPlus64.exe
douyin_widget.exe
DSHost.exe
FFWallpaper.exe
HaloDesktop.exe
HaloDesktop64.exe
iEasyDesk.exe
IEDDW.exe
jldesk.exe
jldesk64.exe
jlwp.exe
kdesk64.exe
kwallpaper.exe
Lively.exe
LiveWallpaper2.exe
MiDesktop.exe
QMDesktopAnimation.exe
QnwPlayer.exe
upupoo-main.exe
wallpaper32.exe
wallpaper64.exe
wmdesktop.exe
wmdesktop64.exe
wps.exe
wpsdesktop.exe
XZDesktop.exe
XZDesktop64.exe


My Computer

System One

  • OS
    Windows 7

My Computers

System One System Two

  • OS
    Windows 11 Pro 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Intel NUC12WSHi7
    CPU
    12th Gen Intel Core i7-1260P, 2100 MHz
    Motherboard
    NUC12WSBi7
    Memory
    64 GB
    Graphics Card(s)
    Intel Iris Xe
    Sound Card
    built-in Realtek HD audio
    Monitor(s) Displays
    Dell U3219Q
    Screen Resolution
    3840x2160 @ 60Hz
    Hard Drives
    Samsung SSD 990 PRO 1TB
    Keyboard
    CODE 104-Key Mechanical with Cherry MX Clears
    Antivirus
    Microsoft Defender
  • Operating System
    Linux Mint 21.2 (Cinnamon)
    Computer type
    PC/Desktop
    Manufacturer/Model
    Intel NUC8i5BEH
    CPU
    Intel Core i5-8259U CPU @ 2.30GHz
    Memory
    32 GB
    Graphics card(s)
    Iris Plus 655
    Keyboard
    CODE 104-Key Mechanical with Cherry MX Clears
Thanks for the list. Have searched for all listed files on my Laptop and nothing found.
So strange that the update is still blocked.


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Asus Zenbook Duo
    Memory
    16 GB
1) Please run the V2 log collector and post a share link into this thread using drop box, or google drive

BSOD - Posting Instructions | Windows 11 Forum (elevenforum.com)


2) Run: upgrade_failure_info > post a share link

https://www.tenforums.com/attachmen...s-use-bsod-debugging-upgrade_failure_info.bat

Batch files for use in BSOD debugging - Windows 10 Help Forums

Batch files for use in BSOD debugging - Windows 10 Help Forums


3) Open administrative command prompt and copy and paste:

schtasks.exe /Run /TN "\Microsoft\Windows\Application Experience\Microsoft Compatibility Appraiser"

reg query "HKLM\SOFTWARE\Microsoft\Windows NT\CurrentVersion\AppCompatFlags\TargetVersionUpgradeExperienceIndicators" /s

Post a share link.


My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
Windows 11 Home
Version: 10.0.22631



There is a gated block:

Code:
Ihr PC wird von dieser Windows 10-Version noch nicht unterstützt. Es ist keine Aktion erforderlich. Diese Windows 10-Version wird von Windows Update automatisch angeboten, sobald das Problem behoben wurde." Title="Ein Upgrade auf Windows 10 ist nicht möglich.

Code:
Your PC is not yet supported by this version of Windows 10. No action is required. Windows Update will automatically offer this version of Windows 10 once the problem is resolved." Title="You cannot upgrade to Windows 10.


0xC1900223, 0x20009
We are exiting in Setup because the machine was Gated BLocked and should not be offered the upgrade.


Please run the Fortinet uninstall tool then attempt an update.

How to uninstall a managed FortiClient in Windows Machines

the steps that need to be taken to uninstall a managed FortiClient using the FC Removal Tool. Scope FortiClient EMS 6.0+, 6.2+, 6.4+, 7.0+, 7.2+ 7.4+. Solution Sometimes there is a need to force the FortiClient uninstallation from an endpoint that has no connection with...
community.fortinet.com community.fortinet.com

If possible temporarily uninstall any / all Fortinet software / drivers.

Start Menu\Programs\FortiClient VPN Public:Start Menu\Programs\FortiClient VPN Public
Name [00000014] Fortinet Virtual Ethernet Adapter (NDIS 6.30)
Name [00000015] Fortinet SSL VPN Virtual Ethernet Adapter
Übertragung bei XOff fortsetzen Nein
Übertragung bei XOff fortsetzen Nein
fortifilter FortiClient NDIS 6.3 Packet Filter Service c:\windows\system32\drivers\fortifilter.sys
ftsvnic Fortinet SSL VPN Virtual Ethernet Adapter c:\windows\system32\drivers\ftsvnic.sys
etc.



In case there is a failure please post new results using English as the default language.



www.tenforums.com

Add, Remove, and Change Display Language in Windows 10

How to Add or Remove Language Packs and Change Display Language in Windows 10
www.tenforums.com www.tenforums.com


www.tenforums.com

Change Display Language in Windows 10

How to Change Display Language in Windows 10
www.tenforums.com www.tenforums.com


My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
reg query "HKLM\SOFTWARE\Microsoft\Windows NT\CurrentVersion\AppCompatFlags" /v WallpaperAppProcessExePath


My Computer

System One

  • OS
    Windows 7
This run reported the gated block:

Code:
GatedBlockId    REG_MULTI_SZ    52754008


Code:
2025-04-10 11:56:31, Info                  CONX   Windows::Compat::Appraiser::SetupAppraiser::StartScan (143):   Start Scan Done
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityHost::SerializeData: Provider wsc:wica: is serializing 956 bytes of data.
2025-04-10 11:56:31, Info       [0x090008] PANTHR CBlackboard::Open: C:\$WINDOWS.~BT\Sources\Panther\CompatScanCache.dat succeeded.
2025-04-10 11:56:31, Info       [0x090009] PANTHR CBlackboard::Close: c:\$windows.~bt\sources\panther\compatscancache.dat.
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityHost::SetScanResult: Provider wsc:wica: reports HardBlock
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityController::ReportData: Type: [0], ID: [3], ReportOption: [2]
2025-04-10 11:56:31, Info                         Reporting block for Categories: 0x01000000
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityController::ReportData: Type: [0], ID: [9], ReportOption: [2]
2025-04-10 11:56:31, Info                         Compatibility scan finished. Categories: 0x01000000
2025-04-10 11:56:31, Info                         Compatibility scan data is saved to C:\$WINDOWS.~BT\Sources\Panther\CompatData_2025_04_10_11_56_31_01000000.xml.
2025-04-10 11:56:31, Info                         Compatibility scan data is saved to C:\$WINDOWS.~BT\Sources\Panther\ScanResult.xml.
2025-04-10 11:56:31, Info                  MOUPG  Scan result at : C:\$WINDOWS.~BT\Sources\Panther\ScanResult.xml
2025-04-10 11:56:31, Info                  MOUPG  CDlpActionCompat::ExecuteGatedScan: Exit
2025-04-10 11:56:31, Info                         Uninitializing compatibility provider wsc:setup:...
2025-04-10 11:56:31, Info                         Uninitializing compatibility provider wsc:wica:...
2025-04-10 11:56:31, Info                  MOUPG  CompatGatedCheck: Leaving Execute Method
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x2004]
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x2003]
2025-04-10 11:56:31, Error                 MOUPG  CDlpActionImpl<class CDlpErrorImpl<class CDlpObjectInternalImpl<class CUnknownImpl<class ICompatAction> > > >::Suspend(1282): Result = 0xC1800104
2025-04-10 11:56:31, Info                  MOUPG  Signalling actions thread to shut down.
2025-04-10 11:56:31, Info                  MOUPG  Waiting for actions thread to exit.
2025-04-10 11:56:31, Info                  MOUPG  Actions thread has exited.
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x2004]
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x2000]
2025-04-10 11:56:31, Error                 MOUPG  CDlpTask::CheckUserInterruptEx(3094): Result = 0x800704D3
2025-04-10 11:56:31, Error                 MOUPG  CDlpTask::CheckUserInterrupt(3147): Result = 0x800704D3
2025-04-10 11:56:31, Info                  MOUPG  DlpTask: Suspending task during action...
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x3000]
2025-04-10 11:56:31, Info                  MOUPG  DlpTask: Leaving Execute Method
2025-04-10 11:56:31, Info                  MOUPG  SetupManager: Found gated compat issues
2025-04-10 11:56:31, Error                 MOUPG  CSetupManager::ExecutePreDownloadMode(10899): Result = 0xC1900223
2025-04-10 11:56:31, Error                 MOUPG  CSetupManager::ExecuteDownlevelMode(602): Result = 0xC1900223
2025-04-10 11:56:31, Info                  MOUPG  Setup phase change: [SetupPhasePreDownload] -> [SetupPhaseError]



Code:
2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,311,Wql Query=SELECT displayName FROM WSC_CallerAMPPLData WHERE (displayName LIKE '%FortiClient%' OR displayName LIKE '%Fortinet AntiVirus%') AND hresultCode != 0

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,402,0x00000001 No wmi object

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,439,WmiQueryMatchingPlugin Matched = 0

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,154,Enter WmiQueryMatchingPlugin

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,AppCompatUtility::CheckCacheMatchingPlugin,89,Found from cache for WmiQueryMatchingPlugin Features FreeFormWhereClause; matched = 1

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,154,Enter WmiQueryMatchingPlugin

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,224,Provider=ROOT\SecurityCenter2;Class=WSC_CallerAMPPLData;Index=0;Name=displayName;Type=wstring;Expected=*;Operation=eq;Timeout=6000

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,311,Wql Query=SELECT displayName FROM WSC_CallerAMPPLData WHERE (displayName LIKE '%FortiClient%' OR displayName LIKE '%Fortinet AntiVirus%') AND iniString = 'INI file too big'

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,402,0x00000001 No wmi object

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,439,WmiQueryMatchingPlugin Matched = 0

2025-04-10 11:56:03, Info                  CONX   Windows::Compat::Appraiser::WicaEngine::RunComponents (1378):   Tier complete: Data Source.
2025-04-10 11:56:03, Info                  CONX   Windows::Compat::Appraiser::WicaEngine::RunComponents (1384):   Tier complete: Decision Maker.
2025-04-10 11:56:04, Info                  CONX   Windows::Compat::Appraiser::WicaEngine::RunComponents (1390):   Tier complete: Decision Aggregator.
2025-04-10 11:56:04, Info                  CONX   Windows::Compat::Appraiser::RegistryMarkerOutputter::AreOldAppraiserMarkersUsable (921):   Old appraiser markers asset not found, unusable.
2025-04-10 11:56:04, Info                  CONX   Windows::Compat::Appraiser::SetupXmlOutputter::WriteGenericMessageHardwareNode (230):   Gating output - default block: [TRUE], default unknown: [FALSE], traditional gated asset count: [0]
2025-04-10 11:56:31, Info                  CONX   Windows::Compat::Appraiser::WicaEngine::RunComponents (1418):   Engine finished.
2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,Windows::Compat::Inventory::InventoryWatchdog::Watch,344,Max lifetime process CPU 0.000000

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,Windows::Compat::Inventory::InventoryWatchdog::Watch,345,Max lifetime process commit 0 bytes

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,Windows::Compat::Inventory::InventoryWatchdog::Watch,353,Stopping InventoryWatchdog.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Windows::Compat::Appraiser::SetupAppraiser::StartScan (143):   Start Scan Done
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityHost::SerializeData: Provider wsc:wica: is serializing 956 bytes of data.
2025-04-10 11:56:31, Info       [0x090008] PANTHR CBlackboard::Open: C:\$WINDOWS.~BT\Sources\Panther\CompatScanCache.dat succeeded.
2025-04-10 11:56:31, Info       [0x090009] PANTHR CBlackboard::Close: c:\$windows.~bt\sources\panther\compatscancache.dat.
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityHost::SetScanResult: Provider wsc:wica: reports HardBlock


My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
zbook said:
This run reported the gated block:

Code:
GatedBlockId    REG_MULTI_SZ    52754008


Code:
2025-04-10 11:56:31, Info                  CONX   Windows::Compat::Appraiser::SetupAppraiser::StartScan (143):   Start Scan Done
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityHost::SerializeData: Provider wsc:wica: is serializing 956 bytes of data.
2025-04-10 11:56:31, Info       [0x090008] PANTHR CBlackboard::Open: C:\$WINDOWS.~BT\Sources\Panther\CompatScanCache.dat succeeded.
2025-04-10 11:56:31, Info       [0x090009] PANTHR CBlackboard::Close: c:\$windows.~bt\sources\panther\compatscancache.dat.
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityHost::SetScanResult: Provider wsc:wica: reports HardBlock
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityController::ReportData: Type: [0], ID: [3], ReportOption: [2]
2025-04-10 11:56:31, Info                         Reporting block for Categories: 0x01000000
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityController::ReportData: Type: [0], ID: [9], ReportOption: [2]
2025-04-10 11:56:31, Info                         Compatibility scan finished. Categories: 0x01000000
2025-04-10 11:56:31, Info                         Compatibility scan data is saved to C:\$WINDOWS.~BT\Sources\Panther\CompatData_2025_04_10_11_56_31_01000000.xml.
2025-04-10 11:56:31, Info                         Compatibility scan data is saved to C:\$WINDOWS.~BT\Sources\Panther\ScanResult.xml.
2025-04-10 11:56:31, Info                  MOUPG  Scan result at : C:\$WINDOWS.~BT\Sources\Panther\ScanResult.xml
2025-04-10 11:56:31, Info                  MOUPG  CDlpActionCompat::ExecuteGatedScan: Exit
2025-04-10 11:56:31, Info                         Uninitializing compatibility provider wsc:setup:...
2025-04-10 11:56:31, Info                         Uninitializing compatibility provider wsc:wica:...
2025-04-10 11:56:31, Info                  MOUPG  CompatGatedCheck: Leaving Execute Method
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x2004]
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x2003]
2025-04-10 11:56:31, Error                 MOUPG  CDlpActionImpl<class CDlpErrorImpl<class CDlpObjectInternalImpl<class CUnknownImpl<class ICompatAction> > > >::Suspend(1282): Result = 0xC1800104
2025-04-10 11:56:31, Info                  MOUPG  Signalling actions thread to shut down.
2025-04-10 11:56:31, Info                  MOUPG  Waiting for actions thread to exit.
2025-04-10 11:56:31, Info                  MOUPG  Actions thread has exited.
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x2004]
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x2000]
2025-04-10 11:56:31, Error                 MOUPG  CDlpTask::CheckUserInterruptEx(3094): Result = 0x800704D3
2025-04-10 11:56:31, Error                 MOUPG  CDlpTask::CheckUserInterrupt(3147): Result = 0x800704D3
2025-04-10 11:56:31, Info                  MOUPG  DlpTask: Suspending task during action...
2025-04-10 11:56:31, Warning               MOUPG  CSetupDiagnostics::ReportData - Not reporting WINDLP data point [0x3000]
2025-04-10 11:56:31, Info                  MOUPG  DlpTask: Leaving Execute Method
2025-04-10 11:56:31, Info                  MOUPG  SetupManager: Found gated compat issues
2025-04-10 11:56:31, Error                 MOUPG  CSetupManager::ExecutePreDownloadMode(10899): Result = 0xC1900223
2025-04-10 11:56:31, Error                 MOUPG  CSetupManager::ExecuteDownlevelMode(602): Result = 0xC1900223
2025-04-10 11:56:31, Info                  MOUPG  Setup phase change: [SetupPhasePreDownload] -> [SetupPhaseError]



Code:
2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,311,Wql Query=SELECT displayName FROM WSC_CallerAMPPLData WHERE (displayName LIKE '%FortiClient%' OR displayName LIKE '%Fortinet AntiVirus%') AND hresultCode != 0

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,402,0x00000001 No wmi object

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,439,WmiQueryMatchingPlugin Matched = 0

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,154,Enter WmiQueryMatchingPlugin

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,AppCompatUtility::CheckCacheMatchingPlugin,89,Found from cache for WmiQueryMatchingPlugin Features FreeFormWhereClause; matched = 1

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,154,Enter WmiQueryMatchingPlugin

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,224,Provider=ROOT\SecurityCenter2;Class=WSC_CallerAMPPLData;Index=0;Name=displayName;Type=wstring;Expected=*;Operation=eq;Timeout=6000

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,311,Wql Query=SELECT displayName FROM WSC_CallerAMPPLData WHERE (displayName LIKE '%FortiClient%' OR displayName LIKE '%Fortinet AntiVirus%') AND iniString = 'INI file too big'

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,402,0x00000001 No wmi object

2025-04-10 11:56:03, Info                  CONX   acmigration: TRACE,WmiQueryMatchingPluginHelper,439,WmiQueryMatchingPlugin Matched = 0

2025-04-10 11:56:03, Info                  CONX   Windows::Compat::Appraiser::WicaEngine::RunComponents (1378):   Tier complete: Data Source.
2025-04-10 11:56:03, Info                  CONX   Windows::Compat::Appraiser::WicaEngine::RunComponents (1384):   Tier complete: Decision Maker.
2025-04-10 11:56:04, Info                  CONX   Windows::Compat::Appraiser::WicaEngine::RunComponents (1390):   Tier complete: Decision Aggregator.
2025-04-10 11:56:04, Info                  CONX   Windows::Compat::Appraiser::RegistryMarkerOutputter::AreOldAppraiserMarkersUsable (921):   Old appraiser markers asset not found, unusable.
2025-04-10 11:56:04, Info                  CONX   Windows::Compat::Appraiser::SetupXmlOutputter::WriteGenericMessageHardwareNode (230):   Gating output - default block: [TRUE], default unknown: [FALSE], traditional gated asset count: [0]
2025-04-10 11:56:31, Info                  CONX   Windows::Compat::Appraiser::WicaEngine::RunComponents (1418):   Engine finished.
2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,Windows::Compat::Inventory::InventoryWatchdog::Watch,344,Max lifetime process CPU 0.000000

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,Windows::Compat::Inventory::InventoryWatchdog::Watch,345,Max lifetime process commit 0 bytes

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,Windows::Compat::Inventory::InventoryWatchdog::Watch,353,Stopping InventoryWatchdog.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Appraiser: TRACE,SdbReleaseDatabase,154,Enter.

2025-04-10 11:56:31, Info                  CONX   Windows::Compat::Appraiser::SetupAppraiser::StartScan (143):   Start Scan Done
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityHost::SerializeData: Provider wsc:wica: is serializing 956 bytes of data.
2025-04-10 11:56:31, Info       [0x090008] PANTHR CBlackboard::Open: C:\$WINDOWS.~BT\Sources\Panther\CompatScanCache.dat succeeded.
2025-04-10 11:56:31, Info       [0x090009] PANTHR CBlackboard::Close: c:\$windows.~bt\sources\panther\compatscancache.dat.
2025-04-10 11:56:31, Info                         ConX::Compatibility::CCompatibilityHost::SetScanResult: Provider wsc:wica: reports HardBlock
Click to expand...
Thanks I already know the GatedBlockId ;-) See my first post.
The problem was which Wallpaper app blocks the update?


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Asus Zenbook Duo
    Memory
    16 GB
garlin said:
reg query "HKLM\SOFTWARE\Microsoft\Windows NT\CurrentVersion\AppCompatFlags" /v WallpaperAppProcessExePath
Click to expand...
Thank you very much, this did the trick.

Now it shows that it is an ASUS app:
HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows NT\CurrentVersion\AppCompatFlags
WallpaperAppProcessExePath REG_SZ C:\Program Files\ASUS\AsusScreenXpert\AsusScreenPadMaxWallpaper.exe


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Asus Zenbook Duo
    Memory
    16 GB
Do you have Armoury Crate installed? It includes the Aura wallpaper extension (which was on the list).


My Computer

System One

  • OS
    Windows 7
You must log in or register to reply here.

Latest Support Threads

Latest Tutorials

Back
Top Bottom
