DISM error: 0x800f081f and WinSxS repair failed.


XYZ123XYZ

Member
Local time
11:57 PM
Posts
7
OS
Windows 11 Pro
When I had a new installation of Windows 11 with version 23H2 (build: 22631.3788), possibly the latest one, and converted via UUP Dump, and then to the ISO image before installation. I had ISO. The Windows Setup and OOBE processes went well. 3 days ago I received an update to version 22631.3810. After the update; then, when I wanted to check it and enter the SFC /Scannow command, it showed that "Windows Resource Protection found corrupt files but was unable to fix some of them" and "The system file repair changes will take effect after the next reboot". I had to restart it otherwise DISM wouldn't let me repair the component store. I wanted to know what the status of the component store is because I thought that after this update, files or folders might be added to WinSxS during Windows updates. It turns out that wasn't the case. Using DISM /Online /Cleanup-Image /CheckHealth and DISM /Online /Cleanup-Image /ScanHealth it said that "The operation was completed successfully".
But when I run the command DISM /Online /Cleanup-Image /RestoreHealth, the error is 0x800f081f (The source files could not be found.
Use the "Source" option to specify the location of the files that are required to restore the feature. For more information on specifying a source location, see Configure a Windows Repair Source)
. I performed some repair actions from the sites:
1. Click Computer Configuration, click Administrative Templates, click System, and then double-click the Specify settings for optional component installation and component repair settings. I set it to Enabled and to download from Windows Update, not WSUS. Doesn't work.
2. I checked the system services (services.msc) after Background Intelligent Transfer Service (BITS), Update Coordinator Service (UsoSvc), Application Identity (AppIDSvc), Windows Update (wuauserv) and it is also not working, intact set by fresh installation.
I recently did an installation on June 20, 2024. I have no idea what could be causing it to work still and I'm wasting a lot of time, even two days. I don't want to reinstall the system again. I'm looking for suggested repairs from the sites, but I don't find anything new. I can provide the entire "C:\Windows\Logs\CBS\CBS.log" and "C:\Windows\Logs\DISM\DISM.log" log files to the website or via Google Drive for analysis.
Is there anything else that can be fixed?

Windows Build/Version
Microsoft Windows 11 Version 23H2, build: 22631.3810

My Computer

System One

  • OS
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    FUJITSU Lifebook A576/M, FMVA1000F, Family: LIFEBOOK-JC
    CPU
    Mobile DualCore Intel Celeron 2950M, 2000 MHz
    Motherboard
    FUJITSU FJNB26E, Chipset: Intel Lynx Point HM86, Intel Haswell
    Memory
    DIMM2: Samsung M471B5173DB0-YK0, DIMM3: Samsung M471B5173QH0-YK0
    Graphics Card(s)
    Video Adapter: Intel Haswell-MB GT1 - Integrated Graphics Controller (Intel(R) HD Graphics)
    Sound Card
    Realtek ALC282, Device ID: 10EC-0282, Subsystem ID: 10CF-2100, Device Description (Windows): Realtek High Definition Audio
    Monitor(s) Displays
    Integrated Monitor [NoDB], Manufacturer: SAMSUNG, Model: 156AT39-701, Manufacture Date: 2015
    Screen Resolution
    1366 x 768; 1360 x 768; 1280 x 768; 1280 x 760; 1024 x 768; 800 x 600; 60p Hz
    Hard Drives
    Model ID: ST320LT012-1DG14C, Serial Number: W3PM8PRA, Revision: 0001SDM1, Device Type: SATA-III, Company Name: Seagate Technology LLC, Hard Disk Name: Momentus Thin 320LT012
    PSU
    Manufacturer: Fujitsu, Device Name: CP700278-01, Serial Number: 01A-Z151022000191Z, Battery Type: Rechargeable Li-Ion
    Keyboard
    Type: Japanese keyboard
    Mouse
    Synaptics PS/2 Port TouchPad
    Internet Speed
    Realtek RTL8168/8111 PCI-E Gigabit Ethernet Adapter, Interface Type: Ethernet; Atheros AR9300 Wireless Network Adapter, Interface Type: 802.11 Wireless Ethernet

My Computer

System One

  • OS
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    FUJITSU Lifebook A576/M, FMVA1000F, Family: LIFEBOOK-JC
    CPU
    Mobile DualCore Intel Celeron 2950M, 2000 MHz
    Motherboard
    FUJITSU FJNB26E, Chipset: Intel Lynx Point HM86, Intel Haswell
    Memory
    DIMM2: Samsung M471B5173DB0-YK0, DIMM3: Samsung M471B5173QH0-YK0
    Graphics Card(s)
    Video Adapter: Intel Haswell-MB GT1 - Integrated Graphics Controller (Intel(R) HD Graphics)
    Sound Card
    Realtek ALC282, Device ID: 10EC-0282, Subsystem ID: 10CF-2100, Device Description (Windows): Realtek High Definition Audio
    Monitor(s) Displays
    Integrated Monitor [NoDB], Manufacturer: SAMSUNG, Model: 156AT39-701, Manufacture Date: 2015
    Screen Resolution
    1366 x 768; 1360 x 768; 1280 x 768; 1280 x 760; 1024 x 768; 800 x 600; 60p Hz
    Hard Drives
    Model ID: ST320LT012-1DG14C, Serial Number: W3PM8PRA, Revision: 0001SDM1, Device Type: SATA-III, Company Name: Seagate Technology LLC, Hard Disk Name: Momentus Thin 320LT012
    PSU
    Manufacturer: Fujitsu, Device Name: CP700278-01, Serial Number: 01A-Z151022000191Z, Battery Type: Rechargeable Li-Ion
    Keyboard
    Type: Japanese keyboard
    Mouse
    Synaptics PS/2 Port TouchPad
    Internet Speed
    Realtek RTL8168/8111 PCI-E Gigabit Ethernet Adapter, Interface Type: Ethernet; Atheros AR9300 Wireless Network Adapter, Interface Type: 802.11 Wireless Ethernet
In this video, i will guide you on how to resolve "The source files could not be found" dism error message.



My Computer

System One

  • OS
    Windows 11
    Computer type
    PC/Desktop
    Manufacturer/Model
    HP Pavilion
    CPU
    AMD Ryzen 7 5700G
    Motherboard
    Erica6
    Memory
    Micron Technology DDR4-3200 16GB
    Graphics Card(s)
    NVIDIA GeForce RTX 3060
    Sound Card
    Realtek ALC671
    Monitor(s) Displays
    Samsung SyncMaster U28E590
    Screen Resolution
    3840 x 2160
    Hard Drives
    SAMSUNG MZVLQ1T0HALB-000H1
This article best describes all the fixes for this error. If it were me I would jump right to doing an repair install. I strongly suggest you backup all your personal data.
Also disable any third party AV software
Repair install Windows 11 with an inplace upgrade Repair Install Windows 11 with an In-place Upgrade Tutorial


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2 22631.3737
    Computer type
    PC/Desktop
    Manufacturer/Model
    Dell Optiplex 7080
    CPU
    i9-10900 10 core 20 threads
    Motherboard
    DELL 0J37VM
    Memory
    32 gb
    Graphics Card(s)
    none-Intel UHD Graphics 630
    Sound Card
    Integrated Realtek
    Monitor(s) Displays
    Benq 27
    Screen Resolution
    2560x1440
    Hard Drives
    1tb Solidigm m.2 nvme+256gb SKHynix m.2 nvme /External +512gb Samsung m.2 sata+1tb Kingston m2.nvme
    PSU
    500w
    Case
    MT
    Cooling
    Dell Premium
    Keyboard
    Logitech wired
    Mouse
    Logitech wireless
    Internet Speed
    so slow I'm too embarrassed to tell
    Browser
    Firefox
    Antivirus
    Defender+MWB Premium
  • Operating System
    Windows 10 Pro 22H2 19045.3930
    Computer type
    PC/Desktop
    Manufacturer/Model
    Dell Optiplex 9020
    CPU
    i7-4770
    Memory
    24 gb
    Monitor(s) Displays
    Benq 27
    Screen Resolution
    2560x1440
    Hard Drives
    256 gb Toshiba BG4 M.2 NVE SSB and 1 tb hdd
    PSU
    500w
    Case
    MT
    Cooling
    Dell factory
    Mouse
    Logitech wireless
    Keyboard
    Logitech wired
    Internet Speed
    still not telling
    Browser
    Firefox
    Antivirus
    Defender+MWB Premium
This article best describes all the fixes for this error. If it were me I would jump right to doing an repair install. I strongly suggest you backup all your personal data.
Also disable any third party AV software
Repair install Windows 11 with an inplace upgrade Repair Install Windows 11 with an In-place Upgrade Tutorial
  1. First, I don't have third-party antiviruses, I only have Microsoft Defender.​
  2. Secondly, I wrote that I don't want to reinstall Windows because I recently made a fresh installation.


My Computer

System One

  • OS
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    FUJITSU Lifebook A576/M, FMVA1000F, Family: LIFEBOOK-JC
    CPU
    Mobile DualCore Intel Celeron 2950M, 2000 MHz
    Motherboard
    FUJITSU FJNB26E, Chipset: Intel Lynx Point HM86, Intel Haswell
    Memory
    DIMM2: Samsung M471B5173DB0-YK0, DIMM3: Samsung M471B5173QH0-YK0
    Graphics Card(s)
    Video Adapter: Intel Haswell-MB GT1 - Integrated Graphics Controller (Intel(R) HD Graphics)
    Sound Card
    Realtek ALC282, Device ID: 10EC-0282, Subsystem ID: 10CF-2100, Device Description (Windows): Realtek High Definition Audio
    Monitor(s) Displays
    Integrated Monitor [NoDB], Manufacturer: SAMSUNG, Model: 156AT39-701, Manufacture Date: 2015
    Screen Resolution
    1366 x 768; 1360 x 768; 1280 x 768; 1280 x 760; 1024 x 768; 800 x 600; 60p Hz
    Hard Drives
    Model ID: ST320LT012-1DG14C, Serial Number: W3PM8PRA, Revision: 0001SDM1, Device Type: SATA-III, Company Name: Seagate Technology LLC, Hard Disk Name: Momentus Thin 320LT012
    PSU
    Manufacturer: Fujitsu, Device Name: CP700278-01, Serial Number: 01A-Z151022000191Z, Battery Type: Rechargeable Li-Ion
    Keyboard
    Type: Japanese keyboard
    Mouse
    Synaptics PS/2 Port TouchPad
    Internet Speed
    Realtek RTL8168/8111 PCI-E Gigabit Ethernet Adapter, Interface Type: Ethernet; Atheros AR9300 Wireless Network Adapter, Interface Type: 802.11 Wireless Ethernet
In this video, i will guide you on how to resolve "The source files could not be found" dism error message.

This video shows how to use the repair from the install.wim file, but there is a very big problem here because I have a very weak Internet to download the latest whole system image with UUP Dump or from the Microsoft website, size: ~6 GB. DISM will not allow me to repair WinSxS if the system image is older, e.g. its version is 22631.3788 and I have 22631.3810, I must agree.


My Computer

System One

  • OS
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    FUJITSU Lifebook A576/M, FMVA1000F, Family: LIFEBOOK-JC
    CPU
    Mobile DualCore Intel Celeron 2950M, 2000 MHz
    Motherboard
    FUJITSU FJNB26E, Chipset: Intel Lynx Point HM86, Intel Haswell
    Memory
    DIMM2: Samsung M471B5173DB0-YK0, DIMM3: Samsung M471B5173QH0-YK0
    Graphics Card(s)
    Video Adapter: Intel Haswell-MB GT1 - Integrated Graphics Controller (Intel(R) HD Graphics)
    Sound Card
    Realtek ALC282, Device ID: 10EC-0282, Subsystem ID: 10CF-2100, Device Description (Windows): Realtek High Definition Audio
    Monitor(s) Displays
    Integrated Monitor [NoDB], Manufacturer: SAMSUNG, Model: 156AT39-701, Manufacture Date: 2015
    Screen Resolution
    1366 x 768; 1360 x 768; 1280 x 768; 1280 x 760; 1024 x 768; 800 x 600; 60p Hz
    Hard Drives
    Model ID: ST320LT012-1DG14C, Serial Number: W3PM8PRA, Revision: 0001SDM1, Device Type: SATA-III, Company Name: Seagate Technology LLC, Hard Disk Name: Momentus Thin 320LT012
    PSU
    Manufacturer: Fujitsu, Device Name: CP700278-01, Serial Number: 01A-Z151022000191Z, Battery Type: Rechargeable Li-Ion
    Keyboard
    Type: Japanese keyboard
    Mouse
    Synaptics PS/2 Port TouchPad
    Internet Speed
    Realtek RTL8168/8111 PCI-E Gigabit Ethernet Adapter, Interface Type: Ethernet; Atheros AR9300 Wireless Network Adapter, Interface Type: 802.11 Wireless Ethernet
  1. First, I don't have third-party antiviruses, I only have Microsoft Defender.​
  2. Secondly, I wrote that I don't want to reinstall Windows because I recently made a fresh installation.


An In-Place Upgrade is a form of repair... it will leave your drivers, programs and files... untouched.

An In-Place Upgrade "compares" what is installed on the computer, with the Windows ISO image.
Then, it overwrites any corrupted Windows files, with clean copies from the ISO image.
This is how it "repairs" Windows while allowing you to keep your programs and personal files.






With the amount of Windows stuff that is broken on your computer, you "need" to do an In-Place upgrade.
It will take weeks to troubleshoot and manually repair everything, IF it can even be repaired manually. ^^

After you download the ISO from Microsoft, the In-Place upgrade will only take about 30 minutes.


Bat File.png




Last edited:

My Computers

System One System Two

  • OS
    Win 11 Home ♦♦♦22631.3810 ♦♦♦♦♦♦♦23H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Built by Ghot® [May 2020]
    CPU
    AMD Ryzen 7 3700X
    Motherboard
    Asus Pro WS X570-ACE (BIOS 4702)
    Memory
    G.Skill (F4-3200C14D-16GTZKW)
    Graphics Card(s)
    EVGA RTX 2070 (08G-P4-2171-KR)
    Sound Card
    Realtek ALC1220P / ALC S1220A
    Monitor(s) Displays
    Dell U3011 30"
    Screen Resolution
    2560 x 1600
    Hard Drives
    2x Samsung 860 EVO 500GB,
    WD 4TB Black FZBX - SATA III,
    WD 8TB Black FZBX - SATA III,
    DRW-24B1ST CD/DVD Burner
    PSU
    PC Power & Cooling 750W Quad EPS12V
    Case
    Cooler Master ATCS 840 Tower
    Cooling
    CM Hyper 212 EVO (push/pull)
    Keyboard
    Ducky DK9008 Shine II Blue LED
    Mouse
    Logitech Optical M-100
    Internet Speed
    300/300
    Browser
    Firefox (latest)
    Antivirus
    Bitdefender Internet Security
    Other Info
    Speakers: Klipsch Pro Media 2.1
  • Operating System
    Windows XP Pro 32bit w/SP3
    Computer type
    PC/Desktop
    Manufacturer/Model
    Built by Ghot® (not in use)
    CPU
    AMD Athlon 64 X2 5000+ (OC'd @ 3.2Ghz)
    Motherboard
    ASUS M2N32-SLI Deluxe Wireless Edition
    Memory
    TWIN2X2048-6400C4DHX (2 x 1GB, DDR2 800)
    Graphics card(s)
    EVGA 256-P2-N758-TR GeForce 8600GT SSC
    Sound Card
    Onboard
    Monitor(s) Displays
    ViewSonic G90FB Black 19" Professional (CRT)
    Screen Resolution
    up to 2048 x 1536
    Hard Drives
    WD 36GB 10,000rpm Raptor SATA
    Seagate 80GB 7200rpm SATA
    Lite-On LTR-52246S CD/RW
    Lite-On LH-18A1P CD/DVD Burner
    PSU
    PC Power & Cooling Silencer 750 Quad EPS12V
    Case
    Generic Beige case, 80mm fans
    Cooling
    ZALMAN 9500A 92mm CPU Cooler
    Mouse
    Logitech Optical M-BT96a
    Keyboard
    Logitech Classic Keybooard 200
    Internet Speed
    300/300
    Browser
    Firefox 3.x ??
    Antivirus
    Symantec (Norton)
    Other Info
    Still assembled, still runs. Haven't turned it on for 13 years?
You also have the DISM.log and CBS.log files for viewing, maybe it will turn out that you don't need to do anything, i.e. Upgrade, download the entire ISO, as I repeat, my Internet is very slow and I won't be able to download and prepare it today. A few errors in the files should give some clue as to what may not be working after using the command.
Link to CBS.log and DISM.log files:


My Computer

System One

  • OS
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    FUJITSU Lifebook A576/M, FMVA1000F, Family: LIFEBOOK-JC
    CPU
    Mobile DualCore Intel Celeron 2950M, 2000 MHz
    Motherboard
    FUJITSU FJNB26E, Chipset: Intel Lynx Point HM86, Intel Haswell
    Memory
    DIMM2: Samsung M471B5173DB0-YK0, DIMM3: Samsung M471B5173QH0-YK0
    Graphics Card(s)
    Video Adapter: Intel Haswell-MB GT1 - Integrated Graphics Controller (Intel(R) HD Graphics)
    Sound Card
    Realtek ALC282, Device ID: 10EC-0282, Subsystem ID: 10CF-2100, Device Description (Windows): Realtek High Definition Audio
    Monitor(s) Displays
    Integrated Monitor [NoDB], Manufacturer: SAMSUNG, Model: 156AT39-701, Manufacture Date: 2015
    Screen Resolution
    1366 x 768; 1360 x 768; 1280 x 768; 1280 x 760; 1024 x 768; 800 x 600; 60p Hz
    Hard Drives
    Model ID: ST320LT012-1DG14C, Serial Number: W3PM8PRA, Revision: 0001SDM1, Device Type: SATA-III, Company Name: Seagate Technology LLC, Hard Disk Name: Momentus Thin 320LT012
    PSU
    Manufacturer: Fujitsu, Device Name: CP700278-01, Serial Number: 01A-Z151022000191Z, Battery Type: Rechargeable Li-Ion
    Keyboard
    Type: Japanese keyboard
    Mouse
    Synaptics PS/2 Port TouchPad
    Internet Speed
    Realtek RTL8168/8111 PCI-E Gigabit Ethernet Adapter, Interface Type: Ethernet; Atheros AR9300 Wireless Network Adapter, Interface Type: 802.11 Wireless Ethernet
Make sure Windows Update working, which Dism tool uses to repair files.


My Computer

System One

  • OS
    Windows 11
    Computer type
    PC/Desktop
    Manufacturer/Model
    HP Pavilion
    CPU
    AMD Ryzen 7 5700G
    Motherboard
    Erica6
    Memory
    Micron Technology DDR4-3200 16GB
    Graphics Card(s)
    NVIDIA GeForce RTX 3060
    Sound Card
    Realtek ALC671
    Monitor(s) Displays
    Samsung SyncMaster U28E590
    Screen Resolution
    3840 x 2160
    Hard Drives
    SAMSUNG MZVLQ1T0HALB-000H1
Make sure Windows Update working, which Dism tool uses to repair files.
The Windows Update service in the UWP Settings application downloads and installs the update, but when I run the command DISM /Online /Cleanup-Image /RestoreHealth, the same error occurs. Internet connectivity via Windows Update works well. I used the command to clean WinSxS: DISM /Online /Cleanup-Image /StartComponentCleanup /ResetBase and then I used this command and it didn't work. I think I have run out of solutions and will have to accept that there will be no component store repair options. I have no chance of downloading entire Windows images because it is a very long download process.


My Computer

System One

  • OS
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    FUJITSU Lifebook A576/M, FMVA1000F, Family: LIFEBOOK-JC
    CPU
    Mobile DualCore Intel Celeron 2950M, 2000 MHz
    Motherboard
    FUJITSU FJNB26E, Chipset: Intel Lynx Point HM86, Intel Haswell
    Memory
    DIMM2: Samsung M471B5173DB0-YK0, DIMM3: Samsung M471B5173QH0-YK0
    Graphics Card(s)
    Video Adapter: Intel Haswell-MB GT1 - Integrated Graphics Controller (Intel(R) HD Graphics)
    Sound Card
    Realtek ALC282, Device ID: 10EC-0282, Subsystem ID: 10CF-2100, Device Description (Windows): Realtek High Definition Audio
    Monitor(s) Displays
    Integrated Monitor [NoDB], Manufacturer: SAMSUNG, Model: 156AT39-701, Manufacture Date: 2015
    Screen Resolution
    1366 x 768; 1360 x 768; 1280 x 768; 1280 x 760; 1024 x 768; 800 x 600; 60p Hz
    Hard Drives
    Model ID: ST320LT012-1DG14C, Serial Number: W3PM8PRA, Revision: 0001SDM1, Device Type: SATA-III, Company Name: Seagate Technology LLC, Hard Disk Name: Momentus Thin 320LT012
    PSU
    Manufacturer: Fujitsu, Device Name: CP700278-01, Serial Number: 01A-Z151022000191Z, Battery Type: Rechargeable Li-Ion
    Keyboard
    Type: Japanese keyboard
    Mouse
    Synaptics PS/2 Port TouchPad
    Internet Speed
    Realtek RTL8168/8111 PCI-E Gigabit Ethernet Adapter, Interface Type: Ethernet; Atheros AR9300 Wireless Network Adapter, Interface Type: 802.11 Wireless Ethernet

Latest Support Threads

Latest Tutorials

Back
Top Bottom
