Questions about Rufus and Windowa 11 installer partitions


Windows 11 User said:
So, having 4 partitions after installing Windows 11 is normal behavior
Click to expand...


YES.
This is what a clean install of Windows 11 will look like...

00000 Default Windows partitions.png


A clean install of Windows 10 will look like this also. Assuming UEFI Bios and GPT disk(s).

This all changed from Windows 7 to Windows 10 and above.
On Windows 7 most people had MBR disk(s), and Legacy Bios.
